Item: 22708

Danoline™ Lay-in Acoustical Perforated Gypsum Panels

Lay-in panels offer excellent acoustics with highly refined aesthetics.

Explore Sizes & Options

Item: 22708

Order a Sample

Overview

Overview

An innovative design balancing aesthetics and acoustics, USG Danoline™ helps you meet the unique challenges of every project – without compromise. Made from gypsum, a sustainable building material, and featuring distinctive perforations, USG Danoline is engineered for an extensive range of technical and design solutions, delivering both performance and elegance to any space.

Perforation Pattern

S3 - Square 1/8" [3.5 mm]

Sound Absorption

0.80 NRC

Light Reflectance

Up To 69.20

Recycled Content

80 %

Main Features

  • Six different perforation patterns to choose from
  • Decorative perforated gypsum panel offers a smooth face with high light reflectance, 69 to 72%
  • Factory applied acoustical backer provides high performance acoustics up to NRC 0.80
  • Higher acoustics achieved with added mineral fiber backer
  • Panels installed with standard acoustical grid system. No special tools or installation required
  • Available in 2'x2', 2'x4' panels
  • Ideal for renovations as well as new construction
  • Panels have a Class A fire rating
  • High recycled content
  • Field modifiable

Specifications

Data Sheet PDF 1.2 MB

Performance

  • Sound Absorption (NRC)
    NRC stands for Noise Reduction Coefficient. It is a measure of how much sound is absorbed by a given material. It is listed as a decimal and relates to percentage sound absorbed.
    0.80
  • Light Reflectance 69.20
  • Mold & Mildew Resistance No
  • Fire Resistance
    • Fire Rating Class A
  • Open Area 16.2%

Sustainability

  • Recycled Content 80%
  • VOC Emissions Low-emitting

Physical Data

  • Thickness (in.) 1/2
  • Color White
  • Edge Flush Narrow (9/16) Edge
  • Panel Size 2 ft. x 2 ft.
  • Material Gypsum

Documents & Files

Data Sheets & Specifications

Data/Submittal Sheet (English) PDF 1.2 MB
Architectural Specification (English) DOCX 114.1 KB

Catalogs & Brochures

System Guide (English) PDF 8.5 MB
Perforation Guide (English) PDF 5.2 MB

SDS, Certifications & Reports

SDS (English) PDF 105.0 KB
SDS (Spanish) PDF 201.3 KB

Warranties

Warranties (English) PDF 146.0 KB

Sustainability

EPD (English) PDF 2.0 MB
