USG “F” Fissured™ Basic Acoustical Panels with USG Donn® Brand Identitee® DXI™ Acoustical Suspension System
USG “F” Fissured™ Basic Acoustical Panels
USG “F” Fissured™ Basic Acoustical Panels with USG Donn® Brand Identitee® DXI™ Acoustical Suspension System
Item: 136

"F" Fissured™ Basic Acoustical Panels

Medium-textured panels featuring sound absorption and durability, these drop ceiling tiles are ideal for offices and restaurants.

Explore Sizes & Options

Item: 136

Acoustics: 0.70 NRC / 35 CAC

Size: 2 ft. x 4 ft.

Color: White

Standard Colors

Order a Sample

Overview

Overview

Featuring excellent sound absorption and a sound barrier backing, these panels are durable and abuse-resistant. "F" Fissured™ Basic Acoustical Ceiling Panels are long-lasting and abuse resistant. Offering sound absorption, these easy-to-clean panels are perfect for administrative offices, schools, financial institutions, religious buildings and restaurants.

Sound Absorption

0.70 NRC

Sound Attenuation

35 CAC

Light Reflectance

Up To 0.79

Recycled Content

69 %

Main Features

"F" Fissured™ Basic Acoustical Ceiling Panels feature high noise reduction coefficients (NRC) and a sound barrier backing. They resist "breathing" (air passing through the surface), staying cleaner longer.
  • Cast product with durable surface that resists scrapes commonly caused by accessing the ceiling plenum
  • Zero VOC emissions exceeds CA Specification 01350
  • USDA Certified Biobased Product
  • Panelsavailable in 2' x 2' and 2' x 4' sizes
  • Available with High Recycled Content (HRC)
  • Class A

Applications

  • Administrative Offices
  • Bars Restaurants and Dining Areas
  • Classrooms
  • Convention and Meeting Rooms
  • Department Stores and Boutiques
  • Executive Areas, Conference Areas and Board Rooms
  • Galleries and Exhibit Spaces
  • Guest Rooms and Suites
  • Lobbies and Reception Areas
  • Mall Interior Spaces
  • Media Centers, Music Rooms and Libraries
  • Nurseries and Birthing Rooms
  • Patient Rooms

Specifications

Data Sheet PDF 1.4 MB

Performance

  • Sound Absorption (NRC)
    NRC stands for Noise Reduction Coefficient. It is a measure of how much sound is absorbed by a given material. It is listed as a decimal and relates to percentage sound absorbed.
    0.70
  • Sound Attenuation (CAC) 35
  • Light Reflectance 0.79
  • Mold & Mildew Resistance No
  • Fire Resistance
    • Fire Rating Class A
  • ASTM E1264
    • astm-e1264-class III: Mineral base with painted finish, D: Fissured, Form 4: Cast or molded
  • ASTM E84
    • Flame Spread 25 or less
    • Smoke Developed 50 or less
    • Fire Rating Class A

Sustainability

  • GREENGUARD Certification Yes
  • Recycled Content 69%
  • VOC Emissions Low-emitting
  • Bio Based Yes

Physical Data

  • Thickness (in.) 3/4
  • Color White
  • Edge Shadowline
  • Panel Size 2 ft. x 4 ft.
  • Material Mineral Fiber

Installation

Installation Guide PDF 822.1 KB

play

USG Ceilings Portfolio Series: Episode 1 - Installation & Edge Style

play

USG Ceilings Portfolio Series: Episode 2 - Performance Features

play

USG Ceilings Portfolio Series: Episode 3 - USG Panel Types

Documents & Files

Data Sheets & Specifications

Data/Submittal Sheet (English) PDF 1.4 MB
Architectural Specification (English) DOCX 108.5 KB

Catalogs & Brochures

System Catalog (English) PDF 45.2 MB
Brochure (English) PDF 1.9 MB

Installation & Technical Manuals

Technical Guide (English)
Installation Guide (English) PDF 822.1 KB

SDS, Certifications & Reports

SDS (English) PDF 136.1 KB
SDS (Spanish) PDF 137.0 KB

Warranties

Warranties (English) PDF 147.7 KB
