Juno™ Acoustical Panels
Mineral fiber panels combining best-in-class sound performance and smooth, non-directional design with durable, encapsulated edges.
Explore Sizes & Options
Fineline
Shadowline
Square EdgeStandard Colors
Overview
Overview
Juno™ Acoustical Panels are designed to bring together the highest performance in both acoustics and aesthetics in an easy to handle mineral fiber package. Juno™ High-NRC panels offer balanced acoustics with a 0.95 NRC and 30 CAC. Fully encapsulated edges provide a premium edge appearance and durability both during and after installation. For the most cohesive look, combine with coordinating USG Donn® Brand Suspension System Premium Profile Collection color Reserve White.
Sound Absorption
0.95 NRC
Sound Attenuation
30 CAC
Light Reflectance
Up To 0.85
Recycled Content
41 %
Main Features
Juno™ Acoustical Panels are manufactured using a unique process that maximizes sound and anti-sag performance. Juno™ High-NRC Acoustical Panels provide an excellent noise reduction coefficient (0.95 NRC) and solid ceiling attenuation class (30 CAC) in a single mineral fiber panel.- Monolithic appearance with smooth, non-directional face finish and durable encapsulated edges
- Washable and scrubbable
- Impact and scratch resistant
- Plant based binder
- Coordinates with USG Donn® Brand grid color Reserve White 4250, available in DXT™, DXF™, DXFF™, and DXI™ suspension system profiles
- ClimaPlus™ 30-year limited system warranty against visible sag, mold and mildew.
- GREENGUARD Gold certified for low emitting performance
- USG Juno™ Acoustical Panels are part of the Ecoblueprint™ portfolio – meeting today’s sustainability standards
- Class A
Applications
- Administrative Offices
- Auditoriums and Gymnasiums
- Classrooms
- Executive Areas, Conference Areas and Board Rooms
- Lobbies and Reception Areas
- Media Centers, Music Rooms and Libraries
- Open Plan Offices
- Traditional Offices
Specifications
Performance
- Sound Absorption (NRC) 0.95
- Sound Attenuation (CAC) 30
- Light Reflectance 0.85
- Mold & Mildew Resistance Yes
-
Fire Resistance
- Fire Rating Class A
-
ASTM E1264
- astm-e1264-class IV: Mineral base with membrane-faced overlay, E: Lightly textured; G: Smooth, Form 1: Nodular; Form 2: Water-Felted
-
ASTM E84
- Flame Spread 25 or less
- Smoke Developed 50 or less
- Fire Rating Class A
Sustainability
- Recycled Content 41%
- VOC Emissions Low-emitting
Physical Data
- Thickness (in.) 1-5/16
- Color White
- Edge Square Edge
- Panel Size 2 ft. x 5 ft.
- Material Mineral Fiber
Warranty
-
Warranty
USG Ceilings Commercial Application Warranty (English) - SC2102PDF 148 KB
Installation
Installation Guide PDF 822.1 KB
Documents & Files
Data Sheets & Specifications
| Data/Submittal Sheet (English) | PDF 1.0 MB |
| Architecturall Specification (English) | DOCX 131.1 KB |
Catalogs & Brochures
| System Catalog (English) | PDF 45.2 MB |
Design Files
| CAD and Revit Files (English) |
Installation & Technical Manuals
| Technical Guide (English) | |
| Installation Guide (English) | PDF 822.1 KB |
SDS, Certifications & Reports
| SDS (English) | PDF 157.0 KB |
| SDS (Spanish) | PDF 157.8 KB |
Warranties
| Warranties (English) | PDF 147.7 KB |
