Item: 141321
Sheetrock® Brand AR Firecode® X Panels
5/8 in. (15.9 mm) Type X panels with abuse resistance (AR) for interior applications
Overview
Overview
Sheetrock® Brand AR Firecode® X Panels (UL Type AR) are 5/8 in. (15.9 mm) Type X panels designed and tested to offer greater resistance to surface abrasion, indentation and impact damage than 5/8 in. (15.9 mm) Sheetrock® Brand Firecode® X Panels. These abuse-resistant panels feature a noncombustible gypsum core that is encased in 100% recycled, heavy duty face and back papers that form a high strength composite design. The face paper is folded around the long edges to reinforce and protect the core, and the ends are cut square and even. The long edges of the panels are tapered, allowing joints to be reinforced and concealed with Sheetrock® Brand joint treatment systems. The panels are UL Classified for fire resistance and can be used in any UL Design in which Type AR panels are listed. On the face, along the long edge of each panel, the UL Type Designation is printed for easy identification by building inspectors.
Main Features
- 5/8 in. (15.9 mm) Type X panels with abuse resistance for interior applications
- Designed and tested to offer greater resistance to surface abrasion, indentation and impact damage than 5/8 in. (15.9 mm) Sheetrock® Brand Firecode® X Panels
- Comply with ASTM C1396, Standard Specification for Gypsum Board, for 5/8 in. (15.9 mm) and Type X gypsum wallboard
- Tested to ASTM C1629, Standard Classification for Abuse-Resistant Nondecorated Interior Gypsum Panel Products and Fiber-Reinforced Cement Panels, for surface abrasion and indentation resistance, and soft- and hard-body impact
- Underwriters Laboratories Inc. (UL) Classification as to fire resistance, surface burning characteristics and noncombustibility
- Achieved GREENGUARD Gold Certification and qualifies as a low VOC emitting material (meets CA 01350)
Applications
- Auditoriums and Gymnasiums
- Bars Restaurants and Dining Areas
- Cafeterias
- Classrooms
- Convention and Meeting Rooms
- Corridors and Hallways
- Department Stores and Boutiques
- Dormitories
- Garages
- Guest Rooms and Suites
- Health and Fitness
- Lobbies and Reception Areas
- Mechanical Rooms
Specifications
Submittal Sheet
PDF 268.0 KB
Performance
- Mold & Mildew Resistance No
-
Fire Resistance
- Fire Rating Type X
-
ASTM E84
- Flame Spread 15
- Smoke Developed 5
- Fire Rating Type X
-
ASTM Type
ASTM C1396; ASTM C1629; ASTM C473; ASTM E136; ASTM E84
- Flame Spread 15
- Smoke Developed 5
- Fire Rating Type X
- UL Type Designations AR
Sustainability
- GREENGUARD Certification Yes
Physical Data
- Thickness (in.) 5/8
- Edge Smooth Wall; Square Edge; Tapered Edge
- Panel Size 48 in. x 8-16 ft.
- Nominal Weight 3.0 lb./sq. ft.
Installation
