Mars™ High-NRC/High-CAC (80/40) Acoustical Panels
Fine-textured panels designed to offer the highest standard in noise reduction or noise isolation.
Explore Sizes & Options
Fineline Bevel
Shadowline Tapered
Square EdgeStandard Colors
Overview
Overview
Mars™ High-NRC Acoustical Ceiling Panels are designed to offer the highest standard in noise reduction (NRC) or noise isolation (40 CAC). Fine-textured and mold resistant, they offer superior sag resistance and high light reflectance values. Their durability, performance and attractiveness make them an ideal choice for an array of spaces. These products provide the industry’s best visual and balanced acoustic performance solution on the market
Sound Absorption
0.80 NRC
Sound Attenuation
40 CAC
Light Reflectance
Up To 0.90
Recycled Content
69 %
Main Features
Mars™ High-NRC / High-CAC (80/40) Acoustical Ceiling Panels are manufactured using a unique process that maximizes sound and anti-sag performance, producing excellent noise reduction coefficient and solid ceiling attenuation class (CAC) performance.- High light-reflective finish (LR-.90) reduces light fixtures and energy use
- Washable and scrubbable finish Plant Based Binder
- Impact and scratch resistant
- Coordinates visually with Halcyon™ Acoustical Panels for open- or closed plan applications
- Non-directional, monolithic visual reduces installation time and waste
- Compatible with Logix™ Integrated Ceiling Systems
- ClimaPlus™ 30-year lifetime system warranty against visible sag, mold and mildew
- Low-emitting product meets CA Specification 01350, California Department of Health Services Standard Practice for the testing of VOC emissions
- Class A
Specifications
Performance
- Sound Absorption (NRC) 0.80
- Sound Attenuation (CAC) 40
- Light Reflectance 0.90
- Mold & Mildew Resistance Yes
-
Fire Resistance
- Fire Rating Class A
-
ASTM E1264
- astm-e1264-class IV: Mineral base with membrane-faced overlay, E: Lightly textured; G: Smooth, Form 1: Nodular; Form 2: Water-Felted
-
ASTM E84
- Flame Spread 25 or less
- Smoke Developed 50 or less
- Fire Rating Class A
Sustainability
- GREENGUARD Certification Yes
- Recycled Content 69%
- VOC Emissions Low-emitting
Physical Data
- Thickness (in.) 1
- Color White
- Edge Shadowline Tapered
- Panel Size 2 ft. x 2 ft.
- Material Mineral Fiber
Warranty
-
Warranty
USG Ceilings Commercial Application Warranty (English) - SC2102PDF 148 KB
Installation
Installation Guide PDF 822.1 KB
Documents & Files
Data Sheets & Specifications
| Data/Submittal Sheet (English) | PDF 2.1 MB |
| Architecturall Specification (English) | DOCX 73.5 KB |
Catalogs & Brochures
| System Catalog (English) | PDF 46.7 MB |
Design Files
| CAD and Revit Files (English) |
Installation & Technical Manuals
| Technical Guide (English) | PDF 1.0 MB |
| Installation Guide (English) | PDF 822.1 KB |
SDS, Certifications & Reports
| SDS (Spanish) | PDF 193.8 KB |
Warranties
| Warranties (English) | PDF 147.7 KB |
