Mars™ High-CAC Acoustical Panels
Fine-textured panels with excellent noise reduction, superior mold- and sag-resistance and high light reflectance.
Explore Sizes & Options
Fineline Bevel
Shadowline Tapered
Square EdgeStandard Colors
Advantage Colors
Premium Colors
Overview
Overview
Mars™ High-CAC Acoustical Ceiling Panels are designed to offer the highest standard in noise reduction (NRC) or Noise Isolation (40 CAC). Fine-textured and mold resistant, they offer superior sag resistance and high light reflectance values. Their durability, performance and attractiveness make them an ideal choice for an array of spaces. These products provide the industry’s best visual and balanced acoustic performance solution on the market
Sound Absorption
0.60 NRC
Sound Attenuation
40 CAC
Light Reflectance
Up To 0.90
Recycled Content
71 %
Main Features
Mars™ High-CACAcoustical Ceiling Panels are manufactured using a unique process that maximizes sound and anti-sag performance, producing excellent noise reduction coefficient (up to .90) and solid ceiling attenuation class (CAC) performance.- Excellent noise reduction (Up to .90 NRC)
- Ceiling Attenuation Class (Up to 40 CAC)
- High light-reflective finish (LR-.90) reduces light fixtures and energy use
- Washable and scrubbable finish Plant Based Binder
- Impact and scratch resistant
- Coordinates visually with Halcyon™ Acoustical Panels for open- or closed-plan applications
- Non-directional, monolithic visual reduces installation time and waste
- Compatible with Logix™ Integrated Ceiling Systems
- ClimaPlus™ 30-year lifetime system warranty against visible sag, mold and mildew
- Available with High Recycled Content (HRC)
- Low-emitting product meets CA Specification 01350, California Department of Health Services Standard Practice for the testing of VOC emissions
- Class A
Applications
- Administrative Offices
- Classrooms
- Convention and Meeting Rooms
- Department Stores and Boutiques
- Executive Areas, Conference Areas and Board Rooms
- Galleries and Exhibit Spaces
- Guest Rooms and Suites
- Lobbies and Reception Areas
- Mall Interior Spaces
- Media Centers, Music Rooms and Libraries
- Nurseries and Birthing Rooms
- Patient Rooms
Specifications
Performance
- Sound Absorption (NRC) 0.60
- Sound Attenuation (CAC) 40
- Light Reflectance 0.90
- Mold & Mildew Resistance Yes
-
Fire Resistance
- Fire Rating Class A
-
ASTM E1264
- astm-e1264-class IV: Mineral base with membrane-faced overlay, E: Lightly textured; G: Smooth, Form 1: Nodular; Form 2: Water-Felted
-
ASTM E84
- Flame Spread 25 or less
- Smoke Developed 50 or less
- Fire Rating Class A
Sustainability
- GREENGUARD Certification Yes
- Recycled Content 71%
- VOC Emissions Low-emitting
Physical Data
- Thickness (in.) 3/4
- Color White
- Edge Fineline Bevel
- Panel Size 2 ft. x 4 ft.
- Material Mineral Fiber
Warranty
-
Warranty
USG Ceilings Commercial Application Warranty (English) - SC2102PDF 148 KB
Installation
Installation Guide PDF 822.1 KB
Documents & Files
Data Sheets & Specifications
| Data/Submittal Sheet (English) | PDF 2.1 MB |
| Architecturall Specification (English) | DOCX 77.7 KB |
Catalogs & Brochures
| System Catalog (English) | PDF 46.7 MB |
Design Files
| CAD and Revit Files (English) |
Installation & Technical Manuals
| Technical Guide (English) | |
| Installation Guide (English) | PDF 822.1 KB |
SDS, Certifications & Reports
| SDS (English) | PDF 191.4 KB |
| SDS (Spanish) | PDF 193.8 KB |
| Certificates (English) | PDF 500.1 KB |
Warranties
| Warranties (English) | PDF 147.7 KB |
